Setting Up Magic IndexedDB in Blazor

Author: Lance Wright II

Published: March 26, 2025

Setting Up Magic IndexedDB in Blazor

1. Install the NuGet Package

The first step is to install the latest version of Magic IndexedDB from NuGet:

🔗 Magic.IndexedDb on NuGet

Before updating, it's highly recommended to review the latest release notes to check for any important changes or enhancements:

🔗 Release Notes & Updates

2. Register the Magic IndexedDB Service

Once installed, you must add the following to your Program.cs file:

🚀 Default Safe Message Limits

// Default safe message limit for WASM applications
builder.Services.AddMagicBlazorDB(BlazorInteropMode.WASM, builder.HostEnvironment.IsDevelopment());

// Default safe message limit for Blazor Hybrid applications (SignalR mode)
builder.Services.AddMagicBlazorDB(BlazorInteropMode.SignalR, builder.HostEnvironment.IsDevelopment());

📏 Custom Message Limit (Advanced)

If you need to customize the message size limit (in bytes), you can specify it manually:

// Custom message limit of 35MB
long customMessageLimitBytes = 35 * 1024 * 1024;
builder.Services.AddMagicBlazorDB(customMessageLimitBytes, builder.HostEnvironment.IsDevelopment());

🔹 Understanding Interop Modes

Interop Mode	Use Case
`BlazorInteropMode.WASM`	Used for standalone Blazor WebAssembly applications
`BlazorInteropMode.SignalR`	Recommended for Blazor Hybrid applications where SignalR is used for communication

The interop mode determines how the JavaScript and C# layers communicate. The message limit controls how much data can be sent between IndexedDB and C#. A higher limit increases speed but also memory usage, so tune it based on your needs.

3. Debug vs. Production Mode

The second parameter in AddMagicBlazorDB is:

builder.HostEnvironment.IsDevelopment()

This boolean indicates whether the application is in Debug mode or not.

🛠 Why This Matters?

When enabled in development, Magic IndexedDB validates your database schema at startup.

It performs system reflection-based validation to detect potential issues early.

In production mode, validation is skipped to avoid unnecessary performance overhead.

AOT Compatibility: Reflection-based validation may not work in Ahead-of-Time (AOT) compiled scenarios.

Keeping it enabled only in development ensures a smooth experience.

TL;DR: In development mode, Magic IndexedDB protects you from mistakes by validating your setup before you run into issues. In production mode, it prioritizes speed and efficiency.

4. Defining Your IndexedDB Schema

Understanding IndexedDB Repositories

Unlike traditional databases, IndexedDB operates differently. Think of repositories like defining tables rather than databases.

To create a schema, define a repository in your Blazor project or any referenced project.

5. Creating the IndexedDB Context

Inside your Blazor project (or a referenced project), create a new C# file (e.g., IndexedDbContext.cs) and implement IMagicRepository:

public class IndexedDbContext : IMagicRepository
{
    public static readonly IndexedDbSet Client = new("Client");
    public static readonly IndexedDbSet Employee = new("Employee");
    public static readonly IndexedDbSet Animal = new("Animal");
}

🔍 How It Works

The system will automatically detect this repository no matter where it is, even if it resides in a referenced project.

It's detected by the IMagicRepository interface itself being attached.

This setup alone is enough to define basic IndexedDB tables.

For complex migration support, additional steps will be needed later.

Defining Tables in Magic IndexedDB

1. Understanding Tables in Magic IndexedDB

Tables in Magic IndexedDB are universally reusable across any IndexedDB database you deploy. Defining a table is as simple as creating a C# class that represents your data and appending it with the appropriate Magic IndexedDB interfaces and tools.

Defines its schema with properties.

Registers its database associations.

Supports compound keys, indexes, and unique constraints.

Automatically migrates when you modify its structure.

2. Creating a Table (Basic Example)

To define a table, you must:

Create a class that represents your data.

Inherit from MagicTableTool<T>.

Implement IMagicTable<TDbSets>.

Define indexes, keys, and other configurations as needed.

📌 Example: Defining a Person Table

public class Person : MagicTableTool<Person>, IMagicTable<DbSets>
{
    public static readonly IndexedDbSet Client = IndexDbContext.Client;

    public IMagicCompoundKey GetKeys() =>
        CreatePrimaryKey(x => x.Id, true); // Auto-incrementing primary key

    public string GetTableName() => "Person";
    public IndexedDbSet GetDefaultDatabase() => IndexDbContext.Client;

    public DbSets Databases { get; } = new();
    public sealed class DbSets
    {
        public readonly IndexedDbSet Client = IndexDbContext.Client;
        public readonly IndexedDbSet Employee = IndexDbContext.Employee;
    }

    [MagicIndex] // Creates an index on this field
    public string Name { get; set; }

    [MagicUniqueIndex("guid")] // Unique constraint
    public Guid UniqueGuid { get; set; } = Guid.NewGuid();

    public int Age { get; set; }

    [MagicNotMapped] // Exclude from IndexedDB schema
    public string Secret { get; set; }
}

3. Breaking Down the Table Definition

🛠 Understanding DbSets

The <TDbSets> type parameter in IMagicTable<TDbSets> exists to enforce clean C# code structure.

You define DbSets however you like, but it must include:

public TDbSets Databases { get; } = new();

This makes the query system strongly typed, allowing clean LINQ queries like:

await _MagicDb.Query<Person>(x => x.Databases.Client);

I suggest simply making a sealed DbSets class inside of each of your classes declared as a table. Then define which databases this table can be associated with. Setting the default database allows you to more easily utilize the table without defining what database to use in the query. This setup is how Magic IndexedDB can provide you the capability to query like:

✅ 1. Default Database Query

IMagicQuery<Person> personQuery = await _MagicDb.Query<Person>();

Targets the default database associated with Person.

If your Person table is linked to a single database, this is the best way to query it.

✅ 2. Querying an Assigned Database (Strongly Typed)

IMagicQuery<Person> employeeDbQuery = await _MagicDb.Query<Person>(x => x.Databases.Client);

Explicitly specifies which database to query.

Person is configured to exist in the Client database, so this is a safe and recommended approach.

4. Defining Keys & Indexes

🔑 Setting the Primary Key

public IMagicCompoundKey GetKeys() =>
    CreatePrimaryKey(x => x.Id, true);

The first parameter is the primary key property.

The second parameter (true or false) sets auto-incrementing behavior.

🗝 Defining a Compound Key

public IMagicCompoundKey GetKeys() =>
    CreateCompoundKey(x => x.Field1, x => x.Field2);

Compound keys combine multiple fields as a unique key.

Auto-incrementing is not allowed on compound keys.

5. Additional Table Configurations

📌 GetTableName() – Table Naming

public string GetTableName() => "Person";

This lets you rename your C# class without breaking migrations.

📌 GetDefaultDatabase() – Default Storage Location

public IndexedDbSet GetDefaultDatabase() => IndexDbContext.Client;

Tells the system which database this table belongs to by default.

6. Using Attributes for IndexedDB Optimization

🔍 MagicName – Rename Columns in IndexedDB

[MagicName("_id")]
public int Id { get; set; }

Ensures column names stay consistent in IndexedDB.

Highly recommended to prevent migration issues when renaming C# properties.

📌 MagicIndex – Create an Indexed Column

[MagicIndex("name")]
public string Name { get; set; }

Speeds up queries using this field.

📌 MagicUniqueIndex – Unique Constraints

[MagicUniqueIndex("guid")]
public Guid UniqueGuid { get; set; } = Guid.NewGuid();

Prevents duplicate values in this column.

📌 MagicNotMapped – Exclude Fields from IndexedDB

[MagicNotMapped]
public string Secret { get; set; }

Keeps the property in C# but out of IndexedDB.

7. Nested Objects in IndexedDB

Yes, Magic IndexedDB supports nested objects!

public class Address
{
    public string City { get; set; }
    public string State { get; set; }
}

public class Person : MagicTableTool<Person>, IMagicTable<DbSets>
{
    public Address HomeAddress { get; set; } = new Address();
}

Fully supported by the custom-built serializer.

Validations ensure that your schema remains stable.

8. Schema Validation & Protection

Magic IndexedDB validates your schema to prevent broken tables:

✔ Ensures compound keys don’t have forbidden names like id.

✔ Protects you from invalid IndexedDB constraints.

Razor Setup

🔹 Add Magic IndexedDB to _Imports.razor

To avoid writing @using Magic.IndexedDb on every page, add it to your _Imports.razor:

@using Magic.IndexedDb

🔹 Inject Magic IndexedDB Into Your Pages

In any Blazor page or component where you want to use Magic IndexedDB, inject the service at the top:

@inject IMagicIndexedDb _MagicDb

Boom! You're plugged in and ready to go! 🎉
